Pump drive SPF 1400

230 V, S3, 10 m cable, with capacitor

680218
680218
PDF product data sheet

Pump drive with multi-vane impeller for faecal wastewater

Item no. 680218
GTIN 4026092066775
Price group 90

    Pump drive SPF 1400 230 V, S3, 10 m cable, with capacitor
    Pump drive with multi-vane impeller for faecal wastewater General characteristics Type of wastewater: with sewage Dimensions Net weight: 27,2 kg Gross weight: 30 kg Packaging dimension: length: 585 mm Packaging dimension: width: 350 mm Packaging dimension: height: 380 mm Pumping device Pump: SPF 1400-S3 Connection type: Direct connection Operating voltage: 230 V Mains frequency: 50 Hz Protection class: I Run dry safe: yes Protection class (pump): IP 68 (3m/48h) Temperature monitoring: integrated Max. temperature (permanent) of conveyed material: 40 °C Max. pumping height: 7 m Speed: 1370 U/min Power P1: 1,6 kW Power P2: 1,1 kW Operating mode: S3 - 50 % Length of mains cable for pump: 10 m Rated current: 7,3 A Control Connection type: Direct connection
      Title Item no.
      Title Item no.
      Title Item no.
      Title Item no.
    • Type of wastewater (abwasserart_de): with sewage
