Control unit Comfort

Mono, 400 V, 1x2,5-4,0 A

680614
PDF product data sheet

Control unit, Comfort 400 V Mono 2.5-4.0 A

Item no. 680614
GTIN 4026092078587
Price group 90

    Control unit Comfort Mono, 400 V, 1x2,5-4,0 A
    Control unit, Comfort 400 V Mono 2.5-4.0 A General characteristics System type: Mono Dimensions Net weight: 2,63 kg Gross weight: 2,98 kg Packaging dimension: length: 395 mm Packaging dimension: width: 195 mm Packaging dimension: height: 320 mm Pumping device Connection type: Direct connection Type of fuse required (electrical protection): C 16 A Control Control unit: Comfort Motor protection switch: no Protection class control unit: IP 54 Connection type: Direct connection Potential-free contact: yes USB interface: yes Log book function: yes Multi-line display: yes Battery buffering: yes Self-diagnosis system (SDS): yes
      Title Item no.
      Title Item no.
      Title Item no.
      Title Item no.
    • Control unit (schaltgeraet): Comfort
