Replacement pump GTF 500
without float switch
Replacement pump without float switch with connection to pressure pipe R 1 1/4", vertical pressure pipe connection, integrated low level suction and removable intake cage and carry handle.
| Item no. | 680773 |
|---|---|
| GTIN | 4026092085110 |
| Price group | 90 |
Replacement pump GTF 500 without float switch
Replacement pump without float switch with connection to pressure pipe R 1 1/4", vertical pressure pipe connection, integrated low level suction and removable intake cage and carry handle. General characteristics Cable length: 10 m Dimensions Net weight: 5,12 kg Gross weight: 6 kg Packaging dimension: length: 276 mm Packaging dimension: width: 241 mm Packaging dimension: height: 382 mm Pumping device Pump: GTF 500 Number of pumps: 1 Operating voltage: 230 V Mains frequency: 50 Hz Run dry safe: yes Protection class (pump): IP 68 Max. pumping height: 8 m Power P1: 0,6 kW Power P2: 0,36 kW Operating mode: S1 Type of fuse required (pump): C 16 A Length of mains cable for pump: 10 m Rated current: 2,7 A Control Mains frequency: 50 Hz Operating voltage: 230 V
| Title | Item no. |
|---|
| Title | Item no. |
|---|
| Title | Item no. |
|---|
| Data Sheet |
|---|
